Emhart Dual Head Gauger

Specification

The standard machine will inspect most containers round and non round in two inspection stations. Spacing of the containers is achieved using an infeed screw.

Faults Detected

Choked Bore (35 to 65mm bore depth), External finish diameter, Height, Dip, Saddle

Container range

Diameter up to 160mm
Height from 72 to 350mm

Speed

Up to 250bpm

Voltages and frequencies

440V
50 - 60 Hz

Compressed Air

1.5 to 4.5 bar (20 to 60 psi) depending on the weight of the container

Weight

400kg
